Workstation One 4 (W-ONE-4)

A new more compact and light Workstation with powerful performance and features

  • 10-zone heated worksurface – with 10 independent
    temperature regulations for maximum temperature stability and uniformity
  • Heated glass stage over viewing area. Thick glass for
    stability, conductivity and does not break
  • 2 incubation compartments integrated in the
    tabletop. No gas or a premixed gas supply as
    standard. With optional CO2 mixing
  • Built-in PC for software or Camera output from
    Microscope
  • Novel APP-based user interface, Via QR codes
  • Patient tracking via app-based user interface
  • HEPA filtration H-14 > 99.995% of particles (0.3μ)
  • Any Microscope can be built in
  • Low noise and pleasant to work with

Temperature

  • 10 Independant PID temperature regulations in the
    heated worksurface
  • Ultimate temperature uniformity and stability
  • Square heated glass stage with thick glass for
    stability and durability
  • Various brands of Microscopes can be integrated
  • Lightbase with 360 degrees tiltable mirror, condenser optics and filter as standard
  • Designed and built for safety and comfort

Patient

  • One compartment one patient
  • Heated lid – PID control
  • Heated bottom – PID control
  • Patient tracking via App and display on lid
  • Fast recovery of conditions
  • Easy opening and closing with a magnet lock
  • No gas, Premixed gas or CO2 mixing options

User interface

  • User interface via app
  • Scan function group and use. Fast and intutive
  • Total documentation of patient flow and
    adjustments done
  • 2 E INK lid displays for patient information

Filters

  • H14 HEPA filters > 99.995% particle retention
  • Prefilter. Carbon or untreated option
  • Inside top surface of the working area is cleanable
    metal and not like a conventional HEPA filter that is fabric
  • Silent operation
  • Reduced height in the design makes cleaning on
    top possible

Parametric data

  • H: 1700 mm + 200 mm with legs/wheels
  • W: 830 mm
  • L: 1240 mm
  • Weight: 180kg
  • Power consumption: 280 W
  • 115/230 V 50/60Hz
  • Temperature range 25 – 40 °C
  • Gas consumption
    < 1 l/h CO2
    < 4 l/h N2
  • Gas pressure
    0,6 Bar (8m7 PSI)
  • CO2 range: 1,9 – 10 %
  • O2 range: 5 – 20 %
